TM3000P Upper Pressure Machine with Automatic Pin Support System
Features
1.Fast speed:
The working period of ordinary workpiece is less than 2 minutes after it enters the main machine, which is 2-4 times of the efficiency of common positive and negative pressure membrane pressure equipment.
2.Good effect:
The product processed by common film has clear groove, no open side, bubbling, no color difference, and high light working surface has strong adhesion, and the effect reaches the international leading level.
3.Low energy consumption:
The total power of the machine is 43KW, which is one half of that of the peer equipment;The main heating starting power is 18KW, and the average power consumption is 13KW/h.
4.High configuration:
The key part of the machine adopts original parts from Germany, Japan and Taiwan, which is high configuration and stable performance.
5.High working efficiency:
The whole machine adopts automatic top block. It saves the technological process of making the pad,saves the scanning sequence of the pad of the equipment, saves the time of laminating process, greatly improves the working efficiency.
6.High degree of automation:
The machine is equipped with automatic fabric selection tilting rack, automatic film cutting device, automatic gasket device, laminating device of pressing machine, pallet lifting device and finished product rollover collection device, etc., with high degree of automation, smooth and close process and one-stop film-covering process production.The height of the top block can be selected 12, 15 and 18 mm, solving the phenomenon that the high-light sample block is not in place.
Outline size 13800mm(11800mm)*2820mm*5200mm
Worktable size 3000mm(2560mm)*1270mm
Weight 24T
Total power 43kw
Maximum processing size 80mm
Voltage 380v 50HZ optional
Rated operating pressure positive ≤0.6Mpa negative ≥-0.095Mpa
